Chevy Has a Shifting Problem

May 3, 2022

This bulletin applies to 2009-2017 Chevy Equinox, Impala, Malibu and Traverse vehicles, equipped with an automatic transmission. The check engine light may be illuminated and in “rare” cases, the PRNDL may not be displayed.

Information courtesy of Mitchell 1

Mike Mavrigian

65b8584a119459001efb6772 Chevytsbshifting

This bulletin applies to 2009-2017 Chevy Equinox, Impala, Malibu and Traverse vehicles, equipped with an automatic transmission. The check engine light may be illuminated. In “rare” cases, the PRNDL may not be displayed. DTC P182E may be set as active or history in the TCM (transmission control module).

Verify proper shift cable adjustment.
Verify proper ECM park/neutral switch status in all shift ranges.
Verify proper internal mode switch (IMS) A/B/C/P parameters in all ranges.
Operate the vehicle within the conditions for running the DTC and freeze frame/failure records data in an attempt to duplicate the DTC. If the DTC does not reset, replace the IMS (lever, manual shift detent with shaft position switch assembly). If the DTC does reset, complete the circuit/system testing steps.

If DTC U0101 is set as active or history in the electronic brake control module, it should be ignored as it has been found to be falsely setting.
