Nissan: Circuit Voltage DTC
This bulletin applies to 2015-2020 Nissan 370Z vehicles equipped with multi-port fuel injection. The MIL may be on accompanied by DTC P0603 (ECM back up/circuit). This DTC may have been stored due to low battery voltage, a discharged battery or battery terminal disconnections.
-
Confirm that battery voltage is at least 11 volts or more with ignition on. Make sure that battery cables are clean and tight.
-
Connect the C-III plus to the vehicle.
-
Open C-III plus on the CONSULT PC.
-
Turn ignition on but do not start the engine.
-
Erase the DTC(s).
-
Turn ignition off.
-
Turn ignition on and wait for at least 1 second.
-
Turn ignition off and wait for at least 10 seconds.
-
Repeat steps 7 and 8.
-
Turn ignition on. If DTC P0603 is not currently stored as a first trip DTC, the procedure is complete.
