Double Check Jeep Electrical Harness Connection

    Aug. 9, 2023
    This bulletin applies to 2014-2015 Jeep Cherokee vehicles equipped with AGS (active grille shutter system). The MIL may be on and DTC U11E9 is either active or stored.
    Jeep
    If this code is present, confirm that the AGS electrical harness is properly connected. Disconnection may have occurred during front fascia service.
    If this code is present, confirm that the AGS electrical harness is properly connected. Disconnection may have occurred during front fascia service.

    This bulletin applies to 2014-2015 Jeep Cherokee vehicles equipped with AGS (active grille shutter system). The MIL may be on and DTC U11E9 is either active or stored. This code refers to lost communication with AGS if the vehicle is started while the AGS electrical harness is disconnected.

    If this code is present, confirm that the AGS electrical harness is properly connected. Disconnection may have occurred during front fascia service.

    About the Author

    Information courtesy of Mitchell 1

    Information for Technical Service Bulletins comes from ProDemand, Mitchell 1's auto repair information software for domestic and import vehicles. Headquartered in San Diego, Mitchell 1 has provided quality repair information solutions to the automotive industry since 1918.
