Jaguar Notes Problem With Pathfinder

Sept. 11, 2020

When carrying out diagnostic sessions on Jaguar E-PACE, F-PACE, E-TYPE, XF or XE using Pathfinder, technicians may observe unknown DTCs being stored in control modules. The DTC information is not being converted correctly between modules and Pathfinder.

Information courtesy of Mitchell 1

Mike Mavrigian

The DTCs and their respective numerical codes are shown below, with the DTC description and symptoms. The DTC index will be corrected in Pathfinder. Please refer to Topix (General Information – Description & Operation – Diagnostic Trouble Code Index) for more information regarding possible causes and actions.

Unknown DTC = Correct DTC

2384640 = P2463-00

Particulate filter restriction – soot accumulation Bank 1

MIL...restricted performance

2386944 = P246C-00

Particulate filter restriction – Forced Limited Power Bank 1

MIL...restricted performance

2386688 = P246B-00

Vehicle Conditions Incorrect for Particulate Filter Regeneration

MIL...restricted performance

2381824 = P2458-00

Particulate Filter Regeneration Duration Bank 1

MIL...restricted performance
