Erase P-Codes in Nissan Before Diagnosing

Sept. 11, 2023

When diagnosing for DTC C1130 (engine signal), for instance on 2012-2017 Nissan Juke vehicles, any P-codes must be diagnosed, repaired and erased first before addressing C-1130.

Information courtesy of Mitchell 1

When diagnosing for DTC C1130 (engine signal), for instance on 2012-2017 Nissan Juke vehicles, any P-codes must be diagnosed, repaired and erased first before addressing C-1130. DTC C1130 is an ABS DTC that indicates an output signal of the ECM is not recognized.

Absent or incorrect ECM signals that are indicated by corresponding P codes may trigger C1130 in the ABS control unit. Some vehicle features that can be affected by absent or incorrect ECM signals include forward emergency braking (FEB), intelligent cruise control (ICC) and VDC/ABS/TCS.
