Some 2014-2020 Toyota 4Runner vehicles may experience the ABS light on with DTC C0226, C0236, C0246 and C0256 stored current in the ABS system. Use a Picoscope to monitor the ground to the skid control ECU with the engine running and headlights on, then with the headlights off.

Information courtesy of Mitchell 1

Mike Mavrigian

Dec. 5, 2022

Add Us On Google

Some 2014-2020 Toyota 4Runner vehicles may experience the ABS light on with DTC C0226, C0236, C0246 and C0256 stored current in the ABS system. Use a picoscope to monitor the ground to the skid control ECU with the engine running and headlights on, then with the headlights off.

Example with headlights off, with aftermarket bulbs. Note the difference in the ground circuit.
|Photo Credit: Mitchell 1

If the ground circuit voltage fluctuates with the headlights on compared to off, inspect the headlight bulbs for any aftermarket parts such as LED or HID bulbs. If aftermarket bulbs are found, perform the same test with factory original bulbs.

Inspect the aftermarket LED or HID headlight bulbs.
|Photo Credit: Mitchell 1
