Funky Fuel Gauge

March 30, 2018
This bulletin applies to 2011-2012 Dodge Journey vehicles equipped with a 3.6L or 2.0L Turbo Diesel engine and 20.5 gallon fuel tank. This bulletin does not apply to vehicles equipped with AWD.

This bulletin applies to 2011-2012 Dodge Journey vehicles equipped with a 3.6L or 2.0L Turbo Diesel engine and 20.5 gallon fuel tank. This bulletin does not apply to vehicles equipped with AWD.

After filling the fuel tank, the customer may notice that the fuel gauge does not read full. On further inspection, the technician will not find any DTCs for this condition. Replacement of the fuel pump module will repair the concern.

This condition will not set any DTCs. However, use a scan tool to check for any of the following DTCs.

P0460-11 (fuel level sensor 1 – circuit short to ground)

P0460-15 (fuel level sensor 1 – circuit short to battery or open)

P2065-11 (fuel level sensor 2 – circuit short to ground)

P2065-15 (fuel level sensor 2 – circuit short to battery or open)

P0461 (fuel level sensor 1 performance)

P0462 (fuel level sensor 1 circuit low)

P0463 (fuel level sensor 1 circuit high)

U110C (lost fuel level message)

U1411 (implausible fuel volume signal received)

FWD Diesel fuel pump module………P/N 05145620AB

FWD gas fuel pump module…………..P/N 05145614AB
