Mazda MIL

Oct. 8, 2013
Some 2004-2009 Mazda vehicles may experience a MIL that comes on with DTC P2004 (variable tumble shutter valve stuck open). The cause may be the check valve in the intake manifold vacuum chamber being stuck open. The check valve has now been updated. Applicable models include 2004-2009 Mazda3 with L3 or LF engines, and 2006-2009 Mazda5 vehicles with the L3 engine.

Some 2004-2009 Mazda vehicles may experience a MIL that comes on with DTC P2004 (variable tumble shutter valve stuck open). The cause may be the check valve in the intake manifold vacuum chamber being stuck open. The check valve has now been updated. Applicable models include 2004-2009 Mazda3 with L3 or LF engines, and 2006-2009 Mazda5 vehicles with the L3 engine.

  1. Verify the concern.
  2. Troubleshoot P2004 following the procedure on MS3 or in the workshop manual, and perform an inspection. If the inspection reveals that the intake manifold is the cause, replace it with an updated one. Refer to MS3 online or workshop manual section 01-13. Note: Replace the throttle body gasket with a new one.
  3. Verify the repair.

PARTS INFORMATION

P/N                              DESCRIPTION                    QTY                    ENGINE

L373-13-100D             Manifold assembly                     1                      L3

LF62-13-100H            Manifold assembly                      1                      LF

L3G2-13-655              Throttle body gasket                    1                     all
