When installing a new fuel pump/fuel gauge sending unit in any Honda car or truck equipped with a
plastic fuel tank, don’t forget to install a new fuel tank lock nut, base basket and fuel line retainers.
When installing a new fuel pump/fuel gauge sending unit in any Honda car or truck equipped with a
plastic fuel tank, don’t forget to install a new fuel tank lock nut, base basket and fuel line retainers.
To
ensure that you’re ordering the correct parts, always refer to the parts catalog. When installing the
gasket, be sure to place it on the fuel tank side, not thon the fuel pump/fuel gauge sending unit side.
This ensures that the gasket does not get pinched or rolled during assembly. If installed incorrectly, the
MIL may illuminate with an EVAP control system leakage DTC.
Information for Technical Service Bulletins comes from ProDemand, Mitchell 1's auto repair information software for domestic and import vehicles. Headquartered in San Diego, Mitchell 1 has provided quality repair information solutions to the automotive industry since 1918.
