Super Duty EGR

March 13, 2017
Some 2008-2010 Ford F-Super Duty trucks equipped with the 6.4L engine and built on or before 11-1-2009 may exhibit a DTC P040D related to the EGR sensor located in the right-hand turbocharger inlet pipe.

Some 2008-2010 Ford F-Super Duty trucks equipped with the 6.4L engine and built on or before 11-1-2009 may exhibit a DTC P040D related to the EGR sensor located in the right-hand turbocharger inlet pipe.

1. Using IDS scan tool, retrieve continuous memory. If DTC P040D is present, proceed to Step 2. If not, refer to the powertrain control/emissions diagnosis manual for normal diagnostics.

2. Turn the ignition switch to the off position.

3. Remove the right hand fender splash shield.

4. Disconnect the glow plug module electrical connectors.

5. Disconnect the inlet EGRT sensor electrical connector.

6. Cut the wire just above the sensor.

7. Apply heat to the sensor mounting boss.

8. Using a 14 mm, 6-point deepwell socket, remove the sensor. Using an open-end wrench is not recommended.

9. Install a new EGRT sensor. Apply a small amount of Motorcraft High Temperature Nickel Anti-Seize lubricant to the threads of the new sensor and tighten to 32 ft.-lbs.

10. Connect the EGRT sensor connector.

11. Connect the glow plug module connectors.Install the fender splash shield.

12. Clear any DTCs.
