Park to Drive Buzz for Ford Explorer

Some 2013-2014 Ford Explorer vehicles may exhibit a growl or buzz noise coming from the transmission that occurs when shifting from park to drive or park to reverse, most often after the vehicle has been parked and then re-started.
,
June 9, 2021
65b858aa23e388001e825c34 Ford2

Some 2013-2014 Ford Explorer vehicles may exhibit a growl or buzz noise coming from the transmission that occurs when shifting from park to drive or park to reverse, most often after the vehicle has been parked and then re-started.

Identify the transmission build date on the transmission identification tag. Replace the main control valve body separator plate or main control assembly as required by the transmission build date.

P/N                                        PART

CL3Z-7Z490-C.......main control valve body separator plate (built between 8-1-2013 and 2-28-2014)

FL3Z-7A100-E.......main control assembly (built between 3-1-2014 and 3-15-2014)

FL3Z-7Z490-E........main control valve body separator plate (built between 3-16-2014 and 7-14-2014)

XT-10-QLVC........Motorcraft MERCON LV ATF

About the Author

Information courtesy of Mitchell 1

Information for Technical Service Bulletins comes from ProDemand, Mitchell 1's auto repair information software for domestic and import vehicles. Headquartered in San Diego, Mitchell 1 has provided quality repair information solutions to the automotive industry since 1918.
